Vanadium (V) Sputtering Targets, Indium
Purity: 99.5%, Size: 3”, Thickness: 0.125”
Sputtering is a proven technology used to deposit thin films from a wide variety of materials onto substrates of different shapes and sizes. The process with sputter targets is repeatable and can be scaled up from small research and development projects. The process with sputter targets can also be adapted for production batches involving medium to large substrate areas. Depending on the process parameters, chemical reactions may occur on the target surface, during flight, or on the substrate. Although sputter deposition involves many variables and is therefore complex, this complexity provides experts with substantial control over film growth and microstructure.
Applications of Sputtering Targets;
Sputtering targets are used for film deposition. The deposition made by sputter targets is a method of depositing thin films by sputtering that involves eroding material from a “target” source onto a “substrate,” such as a silicon wafer. Semiconductor sputtering targets are used to etch the target. Sputter etching is chosen in cases where a high degree of etching anisotropy is required and selectivity is not a concern. Sputter targets are also used for analysis by etching away the target material. One example occurs in secondary ion spectroscopy (SIMS), where the target sample is sputtered at a constant rate. As the target is sputtered, the concentration and identity of sputtered atoms are measured using mass spectrometry. With the assistance of the sputtering target, the composition of the target material can be determined, and even extremely low concentrations of impurities are detected. Sputtering targets also have application in space, as sputtering is one of the mechanisms of space weathering, altering the physical and chemical properties of airless bodies such as asteroids and the Moon.
