| Application |
Details |
| Thin Film Deposition |
Material is eroded from the target onto substrates such as silicon wafers to form thin films. |
|
|
Semiconductor EtchingUsed for sputter etching where high etching anisotropy is needed without selectivity concerns.
|
|
Material Analysis (SIMS)Target is sputtered at a constant rate; mass spectrometry measures atom concentration and identity, enabling detection of trace impurities.
|
| Space / Space Weathering |
Helps study physical and chemical changes on airless bodies, such as asteroids and the Moon. |
