Bismuth Oxide (Bi₂O₃) Sputtering Targets
Purity: 99.9% Size: 3” Thickness: 0.125”
Sputtering is a versatile method for depositing thin films from diverse materials onto substrates of various shapes and sizes. This process is repeatable and scalable, suitable for both research projects and medium-to-large production batches. Chemical reactions may occur on the target surface, in-flight, or on the substrate depending on process parameters, giving experts precise control over film growth and microstructure.
Applications
-
Thin Film Deposition: Material is eroded from a target and deposited onto substrates like silicon wafers.
-
Semiconductor Etching: Ideal for cases requiring high anisotropy etching without strict selectivity.
-
Material Analysis: Supports secondary ion mass spectrometry (SIMS) for precise composition and impurity detection.
-
Space Applications: Contributes to space weathering, altering physical and chemical properties of airless bodies like asteroids and the Moon.
Material Overview
Bismuth oxide (Bi₂O₃) is a critical bismuth compound with valuable optical and electrical properties, including:
-
Energy gap: 2–4 eV
-
High refractive index
-
Strong oxygen ion conductivity at medium and high temperatures
These properties make Bi₂O₃ suitable for:
-
Optoelectronics
-
Solar cells
-
Solid oxide fuel cells (SOFCs)
Bi₂O₃ exists in multiple polymorphs (α, β, γ, δ), each with distinct crystal structures and properties. Only the α-phase (low-temperature monoclinic) and δ-phase (high-temperature face-centered cubic) are stable.
Magnetron sputtering is widely used for high deposition rates, dense and adhesive films, and compatibility with large-area systems. Bi₂O₃-based materials are applied in:
-
Electrolytes for SOFCs and oxygen sensors
-
Gas sensors and optical coatings
-
Ceramic glass production
-
Photocatalysis for water splitting and decontamination under visible light
Additionally, Bi-containing oxides exhibit high charge carrier mobility and long electron mean free paths, making them promising for microelectronics. Semi-metallic Bi thin films transition to semiconductors at thicknesses around 30 nm, enhancing their potential in advanced applications.
