Bismuth Ferrite (BiFeO3) Sputtering Targets, Indium
Purity: 99.9%
Size: 5”
Thickness: 0.250”
Sputtering is a well-established technique for depositing thin films from a wide variety of materials onto substrates of various shapes and sizes. The process is highly repeatable and scalable, suitable for both small research projects and medium-to-large production batches. Chemical reactions may occur on the target surface, in-flight, or on the substrate depending on process parameters, giving experts precise control over film growth and microstructure.
Applications of Sputtering Targets
-
Thin Film Deposition: Material is eroded from the target to deposit films on substrates like silicon wafers.
-
Semiconductor Etching: Provides high etching anisotropy when selectivity is not critical.
-
Analytical Uses: Enables detailed composition analysis and detection of trace impurities, such as in Secondary Ion Mass Spectroscopy (SIMS).
-
Space Applications: Contributes to space weathering, affecting the physical and chemical properties of airless bodies like asteroids and the Moon.
About Bismuth Ferrite (BiFeO3)
Bismuth ferrite (BiFeO3) is an inorganic compound with a perovskite structure and is among the most promising multiferroic materials. Sputtering targets are produced via high-temperature sintering or recrystallization of Bi and Fe oxide mixtures to form single-phase BiFeO3. Indium bonding is recommended for optimal performance.
