Ketjen Black EC-300J Conductive Carbon Black
KETJENBLACK is an electro-conductive carbon black known for exceptional performance and consistent quality. When mixed with plastics, rubber, or other materials, it achieves the same electro-conductivity as conventional carbon blacks but at significantly lower loadings.
Product Properties
| Property | Value |
|---|---|
| Pore Volume, DBP (ml/100g) | 310–345 ml/100g |
| pH | 9.0–10.5 |
| Grit Content | ≤ 30 mg/kg |
| Volatile (wt%) | ≤ 1.0 |
| Ash | ≤ 0.05 % |
| Iodine Value | 740–840 mg/g |
| Fine (wt%) | ≤ 7 |
| Apparent Bulk Density (kg/m³) | 125–145 |
| Moisture (wt%) | ≤ 0.5 |
| Appearance | Black free-flowing pellets |
Applications of Ketjenblack
Ketjenblack EC-300J is a highly pure conductive carbon black ideal for antistatic and electroconductive applications. Its unique morphology and high surface area (~800 m²/g BET) enable equivalent conductivity to conventional conductive blacks at one-third the loading. This reduced loading minimizes mechanical and rheological property loss in polymers sensitive to filler addition. When well dispersed, it significantly improves compound conductivity.
It is compatible with thermoplastics, thermosets, and elastomers, producing conductive materials at low loadings. Low grit content ensures smooth extrusion, and ash levels are suitable for semicon cable shielding. Additional uses include conductive coatings, primers, batteries, IC packaging, tubing, flooring, carpet backing, automotive components, and mobile device parts.
Ketjenblack Features
-
Achieves conventional carbon black conductivity with 1/2 to 1/3 the loading
-
Maintains physical properties of base resins or paint at lower loadings
-
Shows minimal reduction in conductivity when blended with other materials
Electro-Conductive Mechanism
KETJENBLACK’s pore structure and morphology allow superior conductivity performance compared to standard carbon blacks.
Storage
Nano Chicago recommends storing Ketjenblack EC-300J in a dry, ventilated area away from direct sunlight. Packaging may be damaged if exposed to direct sunlight for over 30 minutes.
