Graphene Sheet Size: 10 cm x 10 cm, Highly Conductive, Thickness: 35 µm
Graphene Sheets are among the most advanced materials available today. A graphene sheet is a single-atom-thick, planar layer of carbon atoms arranged in a densely packed hexagonal lattice. These sheets demonstrate exceptional electrical conductivity at room temperature and serve as effective fillers for enhancing the electrical and mechanical performance of composite materials. Graphene sheets play a crucial role in applications involving biomaterials, biosensors, biomedical devices, and drug delivery systems. High-quality Graphene Sheets at competitive prices are available at Nano Chicago.
Technical Properties of Graphene Sheet
Size (cm): 10 × 10
Thickness (µm): 35
Thermal Conductivity In-Plane (W/(m·K)): 1300–1500
Density (g/cm³): 1.6–2.0
Tensile Strength (MPa): 10
Electrical Conductivity In-Plane (S/m): 4×10⁵ ~ 2×10⁶
EMI Shielding (dB @30 MHz – dB @1.5 GHz): 53–58
Electrical Resistivity (Surface, Ω/sq): 0.06
Max Operating Temperature (°C): 450
RoHS Compliant: Yes
Thermal Conductivity & Spreading: In-plane conductivity above 550 W/(m·K)
Electrical Properties: Formulations available with surface resistivity as low as 0.04 Ω/sq
Potential Applications
• Thermal management and heat spreading
• EMI shielding
• Electrodes for batteries and supercapacitors
Current Applications
• Consumer electronics: smartphones, tablets, PCs, TVs
• LED lighting
• Energy storage
• Automotive
• Industrial
• Medical
• Military and aerospace
