Single Walled Carbon Nanotubes (SWCNT) Array on Quartz
Height: 95 µm
Single Walled Carbon Nanotube (SWCNT) Arrays grown on quartz substrates provide a vertically aligned high-purity nanotube structure optimized for electrical and thermal performance. The extremely small nanotube diameters and uniform alignment enable efficient electron transport and rapid heat dissipation, making this material suitable for advanced device engineering.
Technical Properties
| Property | Value |
|---|---|
| SWCNT Purity | 99 wt% |
| Carbon Nanotube Content | >99.5% |
| Outside Diameter | 1–3 nm |
| Inside Diameter | 0.6–1.8 nm |
| Array Height | 95 µm |
| Array Density | <0.30 g/cm³ |
| Specific Surface Area (SSA) | 28 m²/g |
| Electrical Conductivity | 1100 S/m |
Applications
This SWCNT array offers high electrical conductivity and excellent thermal dissipation due to its vertically aligned structure and large surface area. These properties make it well-suited for:
-
Microelectronics
-
Sensors
-
Power devices
-
Thermal management components
