Single Walled Carbon Nanotubes (SWCNT) Array on Quartz
Height: 190 µm
This Single Walled Carbon Nanotube (SWCNT) Array on quartz features extremely high purity and ultra-fine nanotube diameters, forming a vertically aligned structure optimized for conductivity and heat dissipation. The material provides excellent performance for next-generation microelectronic and sensor technologies.
Technical Properties
| Property | Value |
|---|---|
| SWCNT Purity | 99 wt% |
| Carbon Nanotube Content | >99.5% |
| Outside Diameter | 1–3 nm |
| Inside Diameter | 0.6–1.8 nm |
| Array Height | 190 µm |
| Array Density | <0.30 g/cm³ |
| Specific Surface Area (SSA) | 28 m²/g |
| Electrical Conductivity | 1100 S/m |
Applications
The high electrical conductivity and large surface area of this SWCNT array make it suitable for advanced applications such as:
-
Microelectronics
-
Sensors
-
Power electronics
-
Thermal dissipation structures
-
Nanoelectronic device architectures
