Multi Walled Carbon Nanotubes Array on Quartz
Height: 960 µm
Multi Walled Carbon Nanotubes (MWCNTs) Array on Quartz features high-purity nanotubes grown on a quartz substrate, offering excellent electrical conductivity and efficient heat dissipation. Its large surface area and conductive properties make it highly suitable for advanced microelectronics, sensors, and power applications.
Technical Properties
| Property | Value |
|---|---|
| MWCNT Purity | 99 wt% |
| MWCNT Outside Diameter | 7–20 nm |
| MWCNT Inside Diameter | 3–7 nm |
| Array Height | 960 µm |
| Array Density | <0.30 g/cm³ |
| Specific Surface Area (SSA) | 28 m²/g |
| Electrical Conductivity | 1100 S/m |
Applications
-
Microelectronics
-
Sensors
-
Power applications requiring high conductivity and efficient heat dissipation
