Multi Walled Carbon Nanotubes Array on Quartz
Height: 95 µm
Multi Walled Carbon Nanotubes (MWCNTs) Array on Quartz combines high-purity nanotubes with a quartz substrate to provide excellent electrical conductivity and efficient heat dissipation. This structure is ideal for applications in microelectronics, sensors, and power devices due to its unique combination of high surface area and conductive properties.
Technical Properties
| Property | Value |
|---|---|
| MWCNT Purity | 99 wt% |
| MWCNT Outside Diameter | 7–20 nm |
| MWCNT Inside Diameter | 3–7 nm |
| Array Height | 95 µm |
| Array Density | <0.30 g/cm³ |
| Specific Surface Area (SSA) | 28 m²/g |
| Electrical Conductivity | 1100 S/m |
Applications
-
Microelectronics
-
Sensors
-
Power applications requiring high conductivity and efficient heat dissipation
