Stainless Steel Three-Electrode Split Test Cell
24 mm Diameter Insert, Easy to Separate After Testing
The stainless steel split-able test cell is designed for R&D of rechargeable battery materials by testing three electrodes. It allows easy and quick testing of various electrodes by simulating assembled coin cells without the need to crimp actual coin cell cases. Two sides of the test cell connect to both electrodes (anode and cathode), with the middle connected to the reference electrode for monitoring voltage variations. This test cell can accommodate 15 mm diameter electrodes and 24 mm separators.
Technical Properties
| Property | Value |
|---|---|
| Structure | Stainless steel |
| Features | 24 mm diameter insert; Sealed by electrolyte corrosive-proof PTFE O-rings; Electrolyte corrosive-proof PTFE Guide Sleeve capable of withstanding up to 250 ºC; Adjustable spring tension on top to accept various electrode thicknesses; Easy to separate after testing; Small enough to be put into and taken out from a glove box |
Application
Stainless steel Three-Electrode Split Test Cell for R&D, Hi-Voltage Battery – 15 mm Diameter Cell.
