Coin Cell Punching Machine
The Coin Cell Punching Machine is a precision manual disc cutter designed for punching electrodes and separators for coin cell batteries. It is widely used in battery research and development, enabling the preparation of high-quality electrode and separator discs for split test cells and coin cell assemblies.
Product Information
| Parameter | Specification |
|---|---|
| Product Name | Coin Cell Punching Machine |
| Product No | NG10BEW0919 |
| Machine Model | Disc cutter for coin cell electrode punch |
| Operating | Manual |
| Dimension | 110 × 150 × 235 mm |
| Cutting Die Size | Standard configuration: 15, 16, 19 mm; φ8–24 mm can be chosen |
| Punching Stroke | 25 mm |
| Punching Thickness | 0.005–0.5 mm (electrode and separator) |
| Weight | About 6 kg |
| Warranty | One Year limited warranty with lifetime support |
Features
The coin cell disc cutter machine is used for coin cell electrode punching with customized cutting dies. Its operation is simple and lightweight, producing discs suitable for electrodes or separators in split test cells and coin cells for battery research.
