Pneumatic Cylindrical Battery Sealing Machine
Product Specifications
| Property | Specification |
|---|---|
| Product Name | Pneumatic Cylindrical Battery Sealing Machine |
| Dimension | L 290 mm × W 205 mm × H 330 mm |
| Product No | NG10MCHW0964 |
| Weight | 35 Kg |
| Structural Material | 1. Prevents short circuit during battery sealing 2. High-strength chromium steel with environmentally plated and sprayed surface to prevent rust |
| Sealing Dies | Standard 18650 series dies; selectable or matched with other specifications |
| Sealing Trip | 30 mm |
| Sealing Pressure | Manual control valve; max 1 MPa, recommended 0.7 MPa, accuracy ±0.5% |
| Gas Consumption | 480 ml per single seal |
| Exhaust Gas Design | Specially designed exhaust ports; can be externally connected (e.g., KF40) |
| Gas Source | 0.6–0.8 MPa argon, nitrogen, or compressed air (compressed air not recommended in glove box) |
| Warranty | One-year limited warranty with lifetime support |
Features
-
Primarily used for lab battery material research to seal cylindrical batteries.
-
Standard 18650 cylindrical battery sealing mould (1 set, 2 seals); other cylindrical battery moulds are optional.
-
Fully pneumatic operation; no electricity required.
-
Two-step sealing process for enhanced sealing quality.
-
Precise mold design ensures accurate and reliable sealing.
-
Solid steel structure for steady, safe operation.
-
Compact, aesthetically pleasing, easy to maintain, and simple to operate.
-
Gas supplied via compressed air or inert gas cylinder; external connection maintains glove box atmosphere balance.
-
High-precision mold design ensures reliable and consistent sealing.
