Thermoplastic Carbon Paste
Advanced conductive material designed for long-term stability and enhanced performance in Perovskite Solar Cells and other energy applications. With low-temperature drying capability (<100°C) and a sheet resistance of <10 Ω/sq at 25µm thickness, this paste ensures efficient charge transport, minimal energy loss, and superior adhesion.
Technical Properties:
| Property | Value |
|---|---|
| Sheet Resistance | <10 Ω/sq @ 25 µm |
| Drying Temperature | <100°C |
| Adhesion | Excellent (7B) |
| Hardness | 7B |
| Conductivity | High |
| Chemical Resistance | High |
| Applications | Perovskite solar cells, printed electronics, energy storage & battery electrodes, R&D |
Applications:
Perovskite Solar Cells – Improves power conversion efficiency and charge transport. Printed Electronics – Used for flexible circuits and advanced conductive coatings. Energy Storage & Battery Electrodes – Ideal for developing high-performance energy solutions. Research & Development – Trusted in laboratories for innovative photovoltaic and energy applications.
This high-performance thermoplastic carbon paste provides researchers, engineers, and manufacturers with a durable, efficient, and low-temperature drying conductive solution suitable for advanced energy and electronic applications.
